SPO 450

Spotlight

Spo 450 uses the latest 4 in 1 LED technology to get the highest color saturation and exceptional color mixing. The 3 controllable system sections allow for an even more artistic effect to the architectural highlighting. Thanks to the RDM function, the projector instantly gives feedback about its working condition, which simplifies the set-up operations.

IP 67

IP67 certified, the projector perfectly supports a permanent outdoor installation

4-in-1 LEDs

30 RGBL LEDs

Controllable system section

Controllable system section allowing for a more artistic effect to architectural highlighting

Holographic filters

Several holographic filters available, allowing to change the beam angle

4-in-1 LEDs

Latest 4 in 1 LED technology to get the highest color saturation and exceptional color mixing.

Holographic filters

Its different holographic filters of 20°, 40°, 55° or 60° x 10° provide several beam angles for the best expected effect.

Controllable system section

Controllable system section allowing for a more artistic effect to the architectural highlighting.

RDM

Thanks to the RDM function, the projector instantly gives feedback about its working condition, which simplifies the set-up and installation operations.

IP67

IP67 certified, the projector perfectly supports a permanent outdoor installation.

E-Coder

E-Coder to address and set-up.

Environment

The projector supports outdoor temperatures from -40° C to 45° C.

IP connector

The DATA and Power connection cables are fitted with waterproof connectors for outdoor use.
Read more...

Les projecteurs SPO en vidéo

Photometric data

Average beam angle (50%): 6°
Vert. Intensity (cd)  Horiz. Intensity (cd)

LED sources

Connection

Dimensions

Documents

Specifications

Reference
100223
Max. Power
450 W
Lumen
11820 lm
Photometric data
819382 cd (6°)
LEDs
30 x RGBL Multichip
Optics
6°

Accessories

Ref: 100216
Holographic filter 20°
Ref: 100217
Holographic filter 40°
Ref: 100220
Holographic filter 55°
Ref: 100221
Holographic filter 60° x 10°
Ref: 100222
Filter support
Ref: 900225
E-Coder to address and set-up
Download the user manualDownload the spec sheetDownload the IES files
