BAR 27

LED Bar

As a new generation of linear wall washer, Bar 27 is designed as a flexible solution to highlight a large variety of outdoor building structures. The Bar is RDM compatible and can be controlled by 3 sections. Every section requires 1 filter.

IP 66

IP66 certified, the projector perfectly supports a permanent outdoor installation

4-in-1 LEDs

27 RGBL multichip LEDs

Controllable system section

Controllable system section allowing for a more artistic effect to architectural highlighting

Frost filters available

10° x 30°, 15° x 1°, 30° x 1°, 30° x 60°, 60° and 60° x 1°

Multichip LEDS

Latest RGBL multichip LED technology to achieve high saturation levels and exceptional color mixing.

Frost filters available

10° x 30°, 15° x 1°, 30° x 1°, 30° x 60°, 60° and 60° x 1°.

Controllable system section

Its segment control system allows for an even more artistic effect to the architectural enhancement.

RDM

Thanks to the RDM function, the projector instantly gives feedback about its working condition, which simplifies the set-up and installation operations.

IP66

IP66 certified, the projector perfectly supports a permanent outdoor installation.

E-Coder

E-Coder to address and set-up.

Environment

The projector supports outdoor temperatures from -40° C to 45° C.

IP connector

The DATA and Power connection cables are fitted with waterproof connectors for outdoor use.
Read more...

Les barres HALTO en vidéo

Photometric data

Angle d’ouverture Beam (50%) : 15°
Vert. Intensity (cd)  Horiz. Intensity (cd)

LED sources

Connection

Dimensions

Specifications

Reference
100296
Max. Power
60 W
Lumen
1256 lm
Photometric data
16657 cd (15°)
LEDs
27 x RGBL Multichip
Optics
15° (optional: 25°/ 60°/ 40 x 15°/ 10 x 60°)
Sections
3

Accessories

Ref: 100280
Frost filter 30° x 1° (3 pcs for BAR 27)
Ref: 100282
Frost filter 15° x 1° (3 pcs for BAR 27)
Ref: 100284
Frost filter 60° (3 pcs for BAR 27)
Ref: 100286
Frost filter 10° x 30° (3 pcs for BAR 27)
Ref: 100288
Frost filter 60° x 1° (3 pcs for BAR 27)
Ref: 100289
Frost filter 30° x 60° (3 pcs for BAR 27)
Ref : 100292
Barndoors
Ref: 900225
E-Coder to address and set-up
Ref : 100253
REPARTITEUR POUR BAR V2 - DMX / 240V 10A 8 POINTS
Ref : 900130
Combo extension cables (DMX/240V) 3M - 8 PIN
Ref : 900131
Combo extension cables (DMX/240V) 5M - 8 PIN
Ref : 900132
Combo extension cables (DMX/240V) 10M - 8 PIN

Documents

Download the user manual
Download the spec sheet
Download the IES files
